The AI Measurement-Level 3D Scanner combines AI algorithms and real-time meshing technology to offer ultra-high precision, high-speed scanning, and multiple modes for diverse scanning applications.

Product Features

The AI Measurement-Level 3D Scanner offers ultra-high precision, speed, and stability for fast and accurate 3D data acquisition. With the integration of AI algorithms and real-time meshing technology, it provides precise 3D reconstruction for objects. This cutting-edge scanner is capable of delivering exceptional measurement accuracy, with a maximum precision of 0.020mm and a scanning rate of up to 7,100,000 measurements per second. The scanner is equipped with a large scanning area of 650mm x 550mm, and the volume accuracy reaches up to 0.015mm + 0.025mm/m. It features multiple scanning modes for different applications, including high-speed scanning, fine scanning, and deep-hole scanning, making it ideal for detailed and efficient scanning tasks in various industries.

• Specifications:

• Maximum Precision: 0.020mm

• Scanning Rate: 7,100,000 measurements per second

• Maximum Scanning Area: 650mm x 550mm

• Volume Accuracy: 0.015mm + 0.025mm/m

• Maximum Resolution: 0.01mm

• Scanning Modes: High-speed scanning, Fine scanning, Deep-hole scanning
